Specifications
Adhesion Stainless Steel Grate Style
Low Profile 1″ Height
Site Sizable: Modify length and locate outlet placement on site
Waterproofing: PVC/Vinyl liner, Lead/copper pan, Hot mop, Rubber liner, Fiberglass
16 gauge, 304 stainless steel perforated top grate with stainless steel channel
Overall width: 2-15/16″, Min. height above waterproofing: 1-5/16″
Capacity: 9 gallons per minute per outlet. Additional outlets may be added to increase flow rate.
Requires 2″ clamp down floor drain with 2″ throat (strainer size). Not included in complete kit.
S-GRAS 6536: 36″ Complete Kit
S-GRAS 6548: 48″ Complete Kit
S-GRAS 6560: 60″ Complete Kit
S-GRAS 6572: 72″ Complete Kit
S-GRAS 6596: 96″ Complete Kit
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Ten day lead time
Include:
Matte White, Gunmetal, Satin Champagne, Polished Gold, Polished Brass and new Satin Brass.
