Specifications
Center Drain: Requires traditional 4-way floor pitch
5″ x 5″ ABS & Stainless Steel Body
Capacity: 8 gallons per minute per outlet.
LQD 5-2
LQD 5-2I: 5″ Stainless Steel Cover, 2″ outlet and throat, hair strainer, lift-out key, and Cast Iron clamp down drain
LQD 5-2P: 5″ Stainless Steel Cover, 2″ outlet and throat, hair strainer, lift-out key, and PVC clamp down drain
LQD 5-2A: 5″ Stainless Steel Cover, 2″ outlet and throat, hair strainer, lift-out key, and ABS clamp down drain
LQD5 B
LQD5 BP: 5″ Stainless Steel Cover top plate, 2″ throat, hair strainer, lift-out key, and PVC Bonded Flange
LQD5 BA: 5″ Stainless Steel Cover top plate, 2″ throat, hair strainer, lift-out key, and ABS Bonded Flange
LQD5 BS: 5″ Stainless Steel Cover top plate, 2″ throat, hair strainer, lift-out key, and Stainless Steel Bonded Flange
Strainer Only
LQ 5 (finish code required)
Includes: 5″ decorative top plate, 2″ throat, hair strainer, lift-out key
Satin Stainless — SS
Polished Stainless — PS
Satin Bronze — SB
Oil Rubbed Bronze – ORB
Matte Black — BK
Ten day lead time
Include:
Matte White, Gunmetal, Satin Champagne, Polished Gold, Polished Brass and new Satin Brass.
